Aluminium dump trailer 49,7 m³ - 5.779kg
Standard equipment
- Steel / aluminium version with EXTRA Light chassis with fine-grained steel
- ROTOS SCB 3-axle unit with disc brakes 22.5 ET 120
- Air suspension
- Lift axle
- Loading pressure gauge
- Electronic braking System with Roll Stability Program or Roll Stability Support
- Tire pressure control system
- Light supporting structure (only place down when empty)
- Aluminum drop supports (full load supports)
- 6 tires (385/65 R22,5) on aluminium wheels Alcoa Satin ET120
- Lateral underride guard
- Folding rear underride guard
- Smooth outer walls
- Aluminum box body 1/1, door and swing function, with swing frame and bows
- 2 grain pusher with cover
- Grain discharge hopper with bag
- Roller tarpaulin with quick-release device
- 2x LED Reversing light (separately)
- 2 pieces rear mounting - 2 pieces side right and left
Measurements:
- Installation height in length approx. 9.790 mm x 2.440 mm
- Platform panel height approx. 2.100 mm
- Loading height with trailer coupling height (unloaded) 3.655 mm
- Trailer coupling height (unloaded) approx. 1.180 mm
- Trailer coupling height (loaded) approx 1.150 mm
Weights:
- Permissible total weight 36.000 / 39.000kg
- Unloaded weight ca. 5.779 kg
- Payload 30.221 / 33.221 kg
- Saddle load 12.000 / 12.000 kg
- Axle load 24.000 / 27.000 kg
Color scheme:
- Chassis in RAL (7350 schmitzgranit in the front)
- Body in RAL (7035 lichtgrau in the front)
- Tarpaulin in RAL (silver in the front)
Delivery time:
- By agreement
As an option:
- Trailer info system incl. brake pad wear indicator, axle load indicator, mileage etc.
- Electric sliding roof
- we have much more specialties to offer, please contact us
